How a copper strip steel rule auto bender machine works

A copper strip steel rule auto bender machine is a specialized equipment used in the manufacturing of steel rule dies for various industries such as packaging, printing, and die cutting. It is designed specifically for bending copper strips to create precise and customized shapes for steel rule blades. Here's an overview of how a copper strip steel rule auto bender machine works:

1. Designing the Die: The die design is created using computer-aided design (CAD) software, specifying the desired shape, contours, and dimensions of the die.

2. Copper Strip Preparation: Copper strips are selected based on the requirements of the die design and the materials to be cut. The copper strips typically come in coils or straight lengths and are prepared for bending.

3. Loading the Copper Strip: The copper strip is loaded into the auto bender machine, which has a dedicated channel or slot to guide the strip during the bending process.

4. Programming the Auto Bender: The desired bending angles and locations are programmed into the machine based on the die design. This can be done using a computer interface or control panel.

5. Bending Process: The auto bender machine utilizes specialized bending tools and clamps to accurately bend the copper strip at the programmed locations. The bending tools are designed to handle the specific thickness and width of the copper strip.

6. Automated Precision: The auto bender machine ensures consistent and precise bending angles along the length of the copper strip. This helps maintain accuracy and quality in the final steel rule blade.

7. Unloading and Assembly: Once the bending process is complete, the bent copper strip is unloaded from the machine. The bent copper strips are then assembled into the die board or base along with other components, such as ejection rubber, creasing rules, and cutting plates, to form the complete steel rule die.

8. Die Cutting: The finished steel rule die is used in die cutting machines to cut or shape materials according to the design specifications.

The copper strip steel rule auto bender machine automates the bending process, improving efficiency and accuracy in the production of steel rule dies. It eliminates the need for manual bending and reduces human error, resulting in faster production times and consistent die quality.
